Technical Parameter：
Rated Speed：<=2.5m/s
Total Permit Weight : 947-4122KG
Matched Guide Rail : 9mm,10mm,16mm
Structure Form: Cup spring ,Single Moving wedge.
Pulling Form:Arm Swing Linkeage .
Performance Standard:GB7588-2003,EN81-1
Installation Position : Car side ,Countweight side .
