Passenger Elevator: 1600kgs, 1.0 m/s, 4/4/4, Floor Name: G,1,2,3
Machine Room Less,Roping: 2:1. Duplex Mode
Shaft Size: 2900 MM(WIDTH) *2950MM (DEPTH). Overhead:5750mm
Pit:2000mm. G Floor: 4500mm,1:4500mm,2:4500mm
Car finishes must be Hairline Stainless Steel(at the rear car wall, we client need
us to put logo with etching type) .
Door Open Size: 1100Wx 2100H , 2-panel Center Opening.(Provide by Client ).
Detailed Specifications: H.S.S cabin ,Rear Side Special by Client
H.S.S Handrail (FJ-FS04), 3 Side and H.S.S decorative ceiling. (HD-DTA01).
COP (HD-C03)& Sub COP (HD-C04) ,LOP(HD-X05DA)
With Voice Announcer, Language:English.
Lift Brand:Please Put Client's Brand
Marble Floor (FJ-B05D).
Monarch Control system, Input Power Supply: AC380V, 3 Phases, 50HZ.
Gearless Traction Machine with ARD,All Details please see Specification.with
CCTV Cable.
